Inferior STEMI

Study the finding, then test the visual cue against the linked Review and Q-Book material.

View current live plate ↗

THE PLATE02 / 02

IMAGE 01 · 2706 × 1069 px · Cached rendition

Inferior and right ventricular acute STEMI

Native-resolution 12-lead ECG of inferior/right ventricular acute STEMI with visible inferior-lead ST elevation.

Source ↗Original at source ↗Download local file ↓

Credit & reuse

James Heilman, MD · CC BY-SA 3.0 · source_rechecked_this_run

License record ↗ · Media ID MED-4a2ed2284cdefdf80d7b

IMAGE 02 · 1664 × 896 px · Cached rendition

ECG 001.jpg

Native-resolution 12-lead ECG showing inferior ST elevation in II, III, and aVF.

Source ↗Original at source ↗Download local file ↓

Credit & reuse

http://en.wikipedia.org/wiki/User:Glenlarson · CC BY-SA 3.0 · source_rechecked_this_run

License record ↗ · Media ID MED-7e9a36504a659d8950ab

Alternate smaller rendition: MED-35d834631b39ffaa5fdc ↓

01 / WHAT MATTERS ON THE EXAM

Inferior STEMI with RV involvement: ST elevation III > II and in V4R — preload-dependent; fluids, no nitrates.

02 / WHAT TO LOOK FOR

Find ST elevation in II, III, and aVF, then inspect I and aVL for reciprocal depression. Compare the available strips before calling right-ventricular involvement.

03 / WATCH OUT FOR

Inferior STEMI with hypotension and clear lungs should prompt right-sided leads for RV infarction; avoid preload-reducing nitrates and assess carefully before fluid administration.
